The ANT-39000 is a fully ONVIF conformant NDAA Approved 4KP60 H.265 or H.264 HDMI video encoder.
This encoder is best suited to 4KP60 inputs and is fully ONVIF Profile S & G Compliant, meaning this encoder will integrate with any other ONVIF device or VMS, so in installations where compatibility and integration with other software is important this encoder is a great choice. PoE+ power gives more flexible integration options and H.265 enables a low bit rate performance over networks. This encoder also has the added benefit of SRT (secure reliable transport).
Advanced alarm and sensor functions allow for higher-level technical applications and this range comes with management software that provides easy management of multiple devices on a network. This unit can be rack mounted (3 x units per rack) and we can supply this rack (at an additional cost).
Note: This product replaces the ANT-38500 in our range but has a higher power consumption due to a more powerful chipset – so therefore PoE+ is required. It is also an encoder only.
Learn more about the key features
Learn more about the key features
Antrica products are compatible with a range of products
| ANT-39000 | ||
| System | Mode | Encoder |
| System | Standards | ONVIF Profile S, RTSP, RTP, RTMP, MPEG-TS HTTP, SRT |
| System | Latency | >150mS (system dependant) |
| Video | Compression | H.265, H.264, MJPEG |
| Video | Profile | Baseline & High |
| Video | Frame Rate | 1- 60fps (60fps @ 4K Res) |
| Video | Bit Rate | 32Kbps ~ 49,152Kbps for Primary, 32Kbps ~ 4,096Kbps for 2nd, 3rd, 4th Stream |
| Video | Mode | GOP |
| Video | Bit Rate Control | CBR, VBR, Hybrid |
| Video | Min Resolution | 320×240 |
| Video | Max Resolution | 3840 x 2160 P60 (HDMI) |
| Video | Number of Streams | Primary 1 x H.264 ,H.265 + Secondary 3 x H.264,H.265,MJPEG |
| Video | Inputs | 1x HDMI input (2.0) |
| Video | Input Combinations | HDMI Only |
| Video | Outputs | 1 x HDMI |
| Video | Output Combinations | HDMI |
| Video | On Screen Display | Multi-Lingual |
| Audio | Mode | Full Duplex Stereo |
| Audio | Compression | G.711 + AAC |
| Audio | Sample Rate | G.711 : 8 KHz, AAC(Option) : 32 kHz / 44.1 kHz / 48 kHz |
| Audio | Bit Rate | G.711 : 8 KHz, AAC: 32 kHz / 44.1 kHz / 48 kHz |
| Audio | Streaming | 2 Way Stereo |
| Audio | Inputs | Analogue Stereo Jack (1vpp) or Embedded Audio (HDMI) |
| Audio | Outputs | Analogue Stereo Jack (1vpp) or Embedded Audio (HDMI) |
| Network | Interface | 10-100-1000 Ethernet RJ45 |
| Network | Protocols | IPv4/v6, TCP, UDP, IGMP(Multicast), ICMP, DHCP, HTTP, HTTPS, RTMP, SRT, RTP, RTSP, FTP, SNMP, SMTP, UPnP, WS-Discovery, Zero Configuration, NTP, DDNS |
| Network | Security | Password Protection, Ip Address Filtering, HTTPS |
| Network | Configuration | SDK, ONVIF, WEB |
| Data | Type | Serial 2 Way |
| Data | Interface | RS232, RS422, RS485 |
| Data | Protocol | Pelco D + others |
| Data | Alarm | 2 Output + Buzzer |
| Data | Sensor | 2 Input |
| Event | Sources | Motion, Sensor Input, Client Disconnection |
| Event | Actions | Email, FTP, PTZ Preset , Alarm Control, Recording |
| Power | Supply | PoE+ or 12v |
| Power | Adapter input volts | AC 110-240v |
| Power | Adapter Output Voltage | 12v DC |
| Power | Consumption | 24w |
| Recording | Edge Storage | USB 3.0 |
| Temperature | Operating Range | -10 + 50C |
| Physical | Dimensions | 134.08(W) X 125(D) X 36.87(H)mm |
| Physical | Weight | 560g |
| Physical | Housing | Black Aluminum |
| General | Certifications | CE , FCC, RoHS |
| General | Software | IP Finder + VMS |
| General | Warranty | 12 Months |
| General | Remote | N/A |
| General | Reset | Web or external |
| Control & Set Up | Set Up | Web Interface API Document |
| Control | API | |
| Upgrade | Firmware Upgrade | |
| In the Box | Contents | Encoder , 12v Power Supply & Lead & Fixing Kit |
| Power Cable/adapter | 1 of either UK/US/EU/China/Aus |
A few of the applications are:
This product is not limited to the markets and applications described.
