ANT-2204 4 X HDMI HDP60 RACK MOUNTED H.265 VIDEO ENCODER

Product Code: ANT-2204

ANT-2204 4 X HDMI HDP60 RACK MOUNTED H.265 VIDEO ENCODER

Product Overview

The ANT-2204 is an H.265 or H.264 HDP60 4 x HDMI (or DVI with a cable adapter) video encoder. This encoder is best suited to applications requiring a lower cost encoder with H.265 low bit rate performance and where full ONVIF is not required.

The ANT-2204 supports a wide range of streaming protocols such as RTSP, RTMP, MPEG-TS, and uniquely HTTP. This encoder is rack mountable and powered by an internal AC to 12v DC output power supply. It has a loop in and out (for each channel) through the HDMI and is cost-effective considering its powerful performance and combining 4 x inputs in one unit.

This model has been tested and integrated with Hud sports code software and other sports analysis-type software.

Product video

Discover the uses and benefits of H.264 and H.265 video encoders with Les Letwin.

The Key features of ANT-2204

Learn more about the key features

4K High Resolution

1920 x 1080 P60 Max Resolution

h.265

H.265 Video Encoder

hdmi

4 x HDMI or DVI Inputs & Outputs

multiple streams

HTTP, RTSP, RTMP and MPEG-TS over UDP Streaming Supported

rackmounted

Rack mountable 1U

temp

Temperature Operating Range 0 + 50C

The Key features of ANT-2204

Learn more about the key features

4K High Resolution

1920 x 1080 P60 Max Resolution

h.265

H.265 Video Encoder

hdmi

4 x HDMI or DVI Inputs & Outputs

multiple streams

HTTP, RTSP, RTMP and MPEG-TS over UDP Streaming Supported

rackmounted

Rack mountable 1U

temp

Temperature Operating Range 0 + 50C

ANT-2204 compatibility

Antrica products are compatible with a range of products

What markets is this product suitable for?

The ANT-2204, 4 x HDMI & DVI Channel Input H.265 HD 1080P60 Video Encoder is typically used within the following markets and more.

WORLDWIDE SPECIALIST, MANUFACTURER & SUPPLIER OF VIDEO ENCODERS & VIDEO DECODERS

Antrica specialises in Video Encoders and Decoders, offers excellent service and technical support. We supply products worldwide directly or via our Global Distributors.

Discover our FREE no-obligation Loan Scheme where you can try one of our products.
Video Encoders enable us to distribute a whole NVR’s screen over IP, using less bandwidth than sending all the IP streams separately.
Antrica Customer
The Antrica encoder is a vital part of our RAMsys (Remote Alarm Management System) solution. With its low bandwidth requirement, it enables remote site videos to be shared to central headquarters for alarm verification and fast decision making. It is a great product to be part of our ecosystem.
Mark Arcay – InterTech Vision
ANTRICA'S SPECIALIST INSIGHTS AND STEP-BY-STEP SUPPORT HELPED ME TO ENSURE I MADE THE CORRECT PRODUCT CHOICE FOR MY VIDEO ENCODING SOFTWARE. A VERY GOOD SERVICE!
Becca Pye - Chief Technology Officer
Previous slide
Next slide

Product information and support

Learn more about the ANT-2204, 4 x HDMI & DVI Channel Input H.265 HD 1080P60 Video Encoder, including key features and tech specs.
  • 4 x HDMI or DVI
  • H.265 HD Video Encoder
  • Up to 4 x 1920 x 1080 at 60 frames per sec encode
  • Dual streaming per input using an IP LAN ethernet connectionI
  • The 4 x HDMI or DVI inputs and outputs allow for signal bypassing or looping
  • HTTP, RTSP, RTMP and MPEG-TS over UDP
  • Powered via 110/240 v AC input (internal 12 v DC)
  • AAC G711 and MP3 audio
  • Embedded audio in HDMI
  • Rack mountable 1U



SystemModeEncoder
SystemStandardsONVIF Discovery, RTSP, RTMP,HTTP, MPEG-TS
SystemLatency>150mS (system dependant)
VideoCompressionH.265
VideoProfileBase, Main or High
VideoFrame Rate1-60 fps
VideoBit Rate16-12 mbps
VideoModeGOP
VideoBit Rate ControlCBR, VBR
VideoMin Resolution320 x 180
VideoMax Resolution1920 x 1080
VideoNumber of StreamsPrimary 4 x H.264 / Secondary 4 x H.264
VideoInputs4 x HDMI (DVI)
VideoInput CombinationsAll 4 Input
VideoOutputs4 x HDMI (DVI)
VideoOutput CombinationsAll 4 Output
VideoOn Screen DisplayEnglish
AudioModeSimplex Stereo
AudioCompressionG.711 + AAC + MP3
AudioSample RateG711 = 8Khz , AAC= 32/44.1kHz MP3 = 32/44.1kHz
AudioBit RateG711=64kbps, AAC= 24-256kb/s MP3 = 24-256kb/s
AudioStreaming1 Way Stereo
AudioInputsAnalogue Stereo Jack (1vpp) or Embedded Audio
AudioOutputsEmbedded Audio
NetworkInterface10-100 Ethernet RJ45
NetworkProtocolsIPv4, TCP, UDP, IGMP(Multicast), DHCP,HTTP, RTP,RTSP, DNS
NetworkSecurityPassword Protection
NetworkConfigurationSDK, WEB
DataTypeN/A
DataInterfaceN/A
DataProtocolN/A
DataAlarmN/A
DataSensorN/A
EventSourcesN/A
EventActionsN/A
PowerSupply12v Internal
PowerAdapter input voltsAC 110-240v input IEC style kettle lead
PowerAdapter Output Voltage240v Internal
PowerConsumption39w
RecordingEdge StorageN/A
TemperatureOperating Range0 + 50C
PhysicalDimensions490 x 290 x 44 mm
PhysicalWeight3.3kg
PhysicalHousingBlack Aluminum
GeneralCertificationsCE , FCC, RoHS
GeneralSoftwareN/A
GeneralWarranty12 Months
GeneralRemoteN/A
GeneralResetWeb or external
Control & Set UpSet UpWeb Interface API Document
ControlAPI
UpgradeFirmware Upgrade
In the BoxContentsEncoder , Internal Power Supply & Lead, 4 x HDMI, & Rack Mount
Power Cable/adapter1 of either UK/US/EU/China/Aus



A few of the applications are:

  • Encode a PC screen and send to a VMS for monitoring, recording and litigation purposes
  • Encode video from a piece of medical equipment and send to remote consultant to oversee the procedure
  • Encode multiple Set Top Boxes for viewing remotely elsewhere

This product is not limited to the markets and applications described.
