Please see ANT-2551 which replaces the ANT-2501.
Identical except ANT-2551 adds H265 and H264 support.
ANT-2051, 1 x HD-SDI Channel Input H.264 HD 1080P60 Video Encoder is capable of 1 x (1920 x 1080) at 60 frames per sec encode with quad streaming using an IP LAN ethernet connection.
Input and output are provided to allow for signal bypassing or looping. Multiple streaming formats are supported such as HTTP, RTSP, RTMP and MPEG-TS over UDP.
AAC G711 and MP3 audio is supported with 1 channel embedded audio in HD-SDI, 1 channel 3.5mm independent audio. The ANT-2051 is rack mountable.
For a 4 x HD-SDI input variant of this product see ANT-2504.
Approved for use and integration with Hudl.
| System | Mode | Encoder |
| System | Standards | ONVIF Discovery, RTSP, RTMP,HTTP, MPEG-TS |
| System | Latency | >150mS (system dependant) |
| Video | Compression | H.264 |
| Video | Profile | Base, Main or High |
| Video | Frame Rate | 1-60 fps |
| Video | Bit Rate | 16-12 mbps |
| Video | Mode | GOP |
| Video | Bit Rate Control | CBR, VBR |
| Video | Min Resolution | 320 x 180 |
| Video | Max Resolution | 1920 x 1080 |
| Video | Number of Streams | Primary 4 x H.264 / Secondary 4 x H.264 |
| Video | Inputs | 1 x HD-SDI |
| Video | Input Combinations | 1 Input |
| Video | Outputs | 1 x HD-SDI |
| Video | Output Combinations | 1 Output |
| Video | On Screen Display | English |
| Audio | Mode | Simplex Stereo |
| Audio | Compression | G.711 + AAC + MP3 |
| Audio | Sample Rate | G711 = 8Khz , AAC= 32/44.1kHz MP3 = 32/44.1kHz |
| Audio | Bit Rate | G711=64kbps, AAC= 24-256kb/s MP3 = 24-256kb/s |
| Audio | Streaming | 1 Way Stereo |
| Audio | Inputs | Analogue Stereo Jack (1vpp) or Embedded Audio |
| Audio | Outputs | Embedded Audio HD-SDI |
| Network | Interface | 10-100 Ethernet RJ45 |
| Network | Protocols | IPv4, TCP, UDP, IGMP(Multicast), DHCP,HTTP, RTP,RTSP, DNS |
| Network | Security | Password Protection |
| Network | Configuration | SDK, WEB |
| Data | Type | N/A |
| Data | Interface | N/A |
| Data | Protocol | N/A |
| Data | Alarm | N/A |
| Data | Sensor | N/A |
| Event | Sources | N/A |
| Event | Actions | N/A |
| Power | Supply | 12v Internal |
| Power | Adapter input volts | AC 110-240v input IEC style kettle lead |
| Power | Adapter Output Voltage | 240v Internal |
| Power | Consumption | 5w apx |
| Recording | Edge Storage | N/A |
| Temperature | Operating Range | 0 + 50C |
| Physical | Dimensions | 147 x 100 x 40 mm |
| Physical | Weight | 1.1kg |
| Physical | Housing | Black Aluminum |
| General | Certifications | CE , FCC, RoHS |
| General | Software | IP Finder |
| General | Warranty | 12 Months |
| General | Remote | N/A |
| General | Reset | Web or external |
| Control & Set Up | Set Up | Web Interface API Document |
| Control | API | |
| Upgrade | Firmware Upgrade | |
| In the Box | Contents | Encoder , Internal Power Supply & Lead, 4 x HDMI, & Rack Mount |
| Power Cable/adapter | 1 of either UK/US/EU/China/Aus |
A few of the applications are:
This product is not limited to the markets and applications described.
